Vertical Turret Milling Machine
Vertical Turret Milling Machine
YSM-20B SERIES

X/Y/Z travel : 1000(Opt.800)/420/400 mm
Spindle taper : NT40(Ø110)
Spindle motor : 5HP (Opt.7.5HP)
X/Y axis servo motor

Specification

  •  The main casting part is made of meehanite casting.

  • The spindle run on high precision P4 class bearing.

  • The spindle is one piece machined from SCM440 alloysteel, thermal refining, high-frequency and precision polishing.

  •  Milling head type:

        -Steps (S) Inverter (C)

10 Steps
60HZ  75-125-195-280-420-650-1050-1610-2360-3500(RPM)
50HZ  60-100-160-230-350-530-860-1320-1940-2870 (RPM)



    -Inverter type used YASKAWA VFD.


  • Used type B belt drive.

  • Hardened and ground X,Y,Z axes slideway.

  • Turcite-B coated on X Y ways.

  • Square way design on Y and column slideway.

  • X/Y axis double nut ball screw.

YSM-20B SERIES - CATALOG
