Vertical Turret Milling Machine
Vertical Turret Milling Machine
YSM-860 SERIES

X/Y/Z travel : 860/426/470 mm
Spindle taper : NT40(Ø105)
Spindle motor : 5HP
Hardened ground-X/Y/Z
Square way-Y/Z

Specification

  •  The main casting part is made of meehanite casting.

  • The spindle is one piece machined from SCM440 alloysteel, thermal refining, high-frequency and precision polishing.

  •  Milling head type:

    -Steps (S) Inverter (C)



10 Steps
60HZ  70-125-190-285-420-600-1025-1530-2200-3350(RPM)
50HZ  58-110-165-240-360-500-870-1290-1900-2780 (RPM)



20 Steps
50HZ   2P 116-220-330-480-720-1000-1740-2580-3800-5560(RPM)
 4P  58-110-165-240-360-500-870-1290-1900-2780 (RPM)



    -Inverter type used YASKAWA VFD.


  • Maximum spindle speed up to 5560rpm/50HZ

  • Used type B belt drive.

  • Hardened and ground X,Y,Z axes slideway.

  • Turcite-B coated on X Y ways.

  • Square way design on Y and column slideway.

  • X/Y axis are using precision ball screw.

YSM-860 SERIES - CATALOG
