The Optimal Design and High Rigidity Feed System

• The 4 million-pulse/rev high-resolution encoders in all axes enable the utmost precision status.
• The enlarged roller bearing linear motion guides perform extreme rigidity.
• High load high precision ballscrews ensure high speed high precision axial movements.
• Fixed volume lubricant distribution system assures comprehensive lubrication.
• Environmental friendly lubrication-coolant separation design.
• The symmetry design in castings of base, column and headstock etc. ideally diminishes thermal deformation and ensures accuracy.

Isolated Direct Drive Spindle

• Automatic spindle cooling system effectively dissipates heat generated from long runtime through efficient oil cooling circulation.
• Micro oil-air lubrication system consistently injects micro amount of lubricant to spindle bearings for maximizing spindle life.
• Highly reliable helical disc spring design ensures optimal spindle balance.
• Floating cylinder design for tool clamp/unclamp system eliminates unnecessary force on spindle bearings.
• Perpetual pre-load design reduces the effect of spindle thermal growth under long spindle runtime.
