High Precision Hard Jaws & Soft Jaws
Standard hard jaws
HJ

Specification

Dimensions

Model HJ05 HJ06 HJ08 HJ10 HJ12 HJ12-1 HJ15 HJ15-1 HJ-21
J-1 53 67.5 86 99.5 103 103 149 149 165
J-2 23 32 35 40 50 50 62 62 65
J-3 27.5 35 51 54 52 52 86 86 90
J-4 10 12 14 16 21 18 22 22.5 25
J-5 4 5 5 5 5 5 8 5 9
J-6 30.5 39 31 43 62.5 62.5 63 63 104.5
J-7 14 20 25 30 30 30 43 43 50
J-8 25.5 28.5 18 17 40.5 40.5 34 34 55
J-9 13.5 17 19 19 25 22 32 32 32
J-10 8.5 11 13 13 17 15 21 21 21
J-11 10 12 12 13 17 17 20 20 40
J-12 M8 M10 M10 M12 M16 M14 M20 M20 M20
J-13 6 10 12 15 30 30 40 40 55
Serration 1.5x60° 1.5x60° 1.5x60° 1.5x60° 1.5x60° 1.5x60° 1.5x60° 1.5x60° 3.0x60°
Reference B B A A B   A   B
