Power Chucks for CNC Lathes
Vertical power chuck
DOV

Specification

Specification

Dim\Model 6" DOV 8" DOV
Piston Dia (mm) Ø115 Ø155
Piston Area - Push Side (cm²) 104 187
Piston Area - Pull Side (cm²) 78.5 148.6
Piston Stroke (mm) 20 17
Max. Draw Bar Pull - Push Side (kgf) 1900 3600
Max. Draw Bar Pull - Pull Side (kgf) 1400 2800
Weight (kg) 12 21
Max. Operation pressure (kgf/cm²) 20 20
Matching Chuck V-206 V-208

Dimensions

Dim\Model 6" DOV 8" DOV
A 220 285
B 205 250
C Ø104.8 Ø133.4
D Ø168 Ø210
E Ø140 Ø170
F Ø55 Ø70
G 60 80.5
I 16 24
K 5.5 5.5
L 15 15
M 50 60
N M14xP2.0 M16xP2.0
O M12D24 M12D24
P 4-Ø13 4-Ø13
Q PT 1/4" PT 1/4"
