High Speed Hollow Hydraulic Cylinders
Short type cylinder
RCS

Specification

Specification

Symbol\Model RCS-6 RCS-8 RCS-10
Effective Piston Area - Extend (cm²) 100 148 183
Effective Piston Area - Retract (cm²) 89 138 169
Piston stroke (mm) 15 22 25
Max. speed (r.p.m.) 8000 6500 5500
Max. pressure (kgf/cm²) 40 40 40
Moment of inertia (kgf.m²) 0.071 0.129 0.251
Weight (kg) 9 13 18.7
Max oil leakage from drain port and max internal oil leakage (lit/min) 3 3.8 4.1

Dimensions

Symbol\Modell RCS-6 RCS-8 RCS-10
C 165 185 215
D 130 170 190
E 100 130 160
F 80 85 120
G 65 70 95
H M55x2.0 M60x2.0 M85x2.0
J Through-Hole Diameter 46 52 75
K 40 40 46
M 52.9 59.6 84.6
N 64 73 98
P 85 96 121
S 116 135 163
T 120 130 160
U 120 150.5 169.5
V (Max) 14 21 24
V (Min) -1 -1 -1
W (Max) 40 42 50
W (Min) 25 20 25
Z 5 5 5
A 98 110 155
B 147 165 195
Symbol\Modell RCS-6 RCS-8 RCS-10
A1 10.5 11.5 17.5
B1 105 110.5 125.5
C1 30 30 35
E1 Depth M6x6 M6x9 M6x10
F1 Depth M10x20 M10x20 M10x20
G1 101.5 110.5 126.5
J1 76 86 101
K1 47 47 47
L1 15 15 15
M1 50 55 82
N1 76 85 108
P1 1.5 3 3
Q1 Depth M5x6 M6x7 M6x7
R1 5 5 7
S1 PT 3/8 PT 1/2 PT 1/2
T1 8 6 6
W1 M52x1.5 M58x1.5 M84x2.0
X1 50 56 81
Y 6-M8x75 6-M8x80 6-M10x90
