Performance and characteristic
1. The system is configured with 3 action modes
a. Lubricating: When turning on, execute lubricating timing
b. Intermittent: Execute intermittent timing after lubricating is completed
c. Memory: In case of power on after power on, resume incomplete intermittent time

2. Lubricating time and intermittent time can be adjusted. (Built-in locking function, and lubricating and intermittent time after setting is locked.)

3. Provided with liquid level switch and pressure switch (optional). When oil volumetric pressure is insufficient, the beeper alarms to send the abnormal signal out.
a. when pressure is insufficient, Erp is displayed.
b. when liquid level is insufficient, Ero is displayed.

4. The system time can be configured, LUB lubricating time; 1-999(seconds)
INT intermittent time:1-999(minutes)(tailored if specially required)

5. The panel indicator displayed lubricating and intermittent status.

6.The system uses RST key to force lubricating or eliminate abnormal reporting signal.

7. Motor continuously operated.

8. Decompression device is provided with volumetric system, used with proportional joint distributor.

9. Overflow is provided with to protect oil injector and pipeline from being damaged by high pressure.
