Gun Drilling Machine
Gun Drilling Machine
SL1000B

Special design for center-hole drillng, like eject hole, automobile parts, medical parts, ect.
To increase the concentricity of hole, spindle and componet are rotating as drilling.
The fixture system is with manual chucks. Hydraulic chucks are available.
Slide ways are hot-treatment to hardness HRC 60 and ground way are based on mechanic cast iron. The opposite ways and gibs are all Turcite-B plated with hand scraped bearing surface.
The enhanced ribs in the major construction provide the excellent rigidity for drilling big size of holes.
Automatic lubrication pump is provided as standard accessory to ensure all bearing surface and screws are well lubricated.
Four filtration systems ( paper filter, magnetic separator, filtration can and oil & chip spearator) are standard accessories to keep the oil clean.
The excellent design of oil flow cycle provides plentiful oil to lower the temperature of drilling and drill smoothly.

Specification

Capacity
  • Number of drill spindle: 2 Nos
  • Range of drilling dia.: 3 ~ 12mm ( 5 ~ 25mm )
  • Max. depth of drilling: 1,000mm



Speed
  • Drill feed range: 10 ~ 500 mm/min
  • Spindle speed range: 6,000 rpm



Hydraulic system

  • Coolant pump pressure range: 10~100 kg/cm²
  • Pump output range: 30~60 L/min
  • Coolant tank capacity: 1200 L



Working table stroke
  • Effective drill stroke (Z-Axis): 1,000mm



Drive motor
  • Spindle motor: 5hp x 2  ( 10hp x 2 )
  • Z-Axis: 2hp
  • Chip screw: 1/8hp
  • Workpiece driven motor: 1hp
  • Coolant pump: 7.5hp x 2 ( 10hp x 2 )
  • Automatic lubrication: 51w
  • Total machine power: 35hp / 50hp
  • Net weight: 3,500kgs
  • Machine dimensions(Approx): 3,800 x 3,500 x 1,700mm

Standard accessories
  • Paper filter
  • Magnetic separator
  • Chip and oil separator system
  • High pressure oil pump
  • Auto lubrication system
  • Protecting drill torsion system
  • Outer oil tank/Oil level gauge
  • Tranformer
  • Leveling screws & block
  • Tool box / work light / alarm light
  • Mechanical / Electrical operation manual

Special accessories
  • Oil cooler
  • Coolant oil
  • Gundrill
  • Guide bush
  • Rubber bush
  • Automatic Voltage stabilizer
  • Fully enclosed guard
  • Gundrill grinder
  • Safety door interlock
  • Oil mist collector
  • Filtration housing
  • Centrifuge



Order Information:
  • Minimum Order: Negotiable
  • Branded Product
  • FOB: Taichung or Keelung Port, Taiwan
