Gun Drilling Machine
Gun Drilling Machine
PLC SL-1500D

Special for long round bar material. (Single spindle, Manual clamping)
Spindle and component are rotating as drilling to increase the concentricity of hole.
With manual three-jaw chuck, clamping range is flexible.
With movable rear fixture base, the base can be moved per the length of round bar.
Fixture device also can be used hydraulic chunks per the shape of bar.

Specification

Capacity

  • Number of drill spindle: 1 No
  • Range of drilling dia.: 3 ~ 25mm
  • Max. depth of drilling: 1,500mm


Speed

  • Drill feed range: 10 ~ 500 mm/min
  • Spindle speed range: 6,000 rpm


Hydraulic system

  • Coolant pump pressure range: 10~100 kg/cm²
  • Pump output range: 30~60 L/min
  • Coolant tank capacity: 1500 L


Working table stroke

  • Effective drill stroke (Z-Axis): 1,500mm


Drive motor

  • Spindle motor: 10hp
  • Z-Axis: 2hp
  • Chip screw: 1/8hp
  • Workpiece driven motor: 1hp
  • Coolant pump: 10hp
  • Automatic lubrication: 40w
  • Total machine power: 28hP
  • Net weight: 6,000kgs
  • Machine dimensions(Approx): 6,000 x 3,500 x 1,700mm


Standard accessories

  • Paper filter
  • Magnetic separator
  • Chip and oil separator system
  • High pressure oil pump
  • Auto lubrication system
  • Protecting drill torsion system
  • Outer oil tank/Oil level gauge
  • Tranformer
  • Leveling screws & block
  • Tool box / work light / alarm light
  • Mechanical / Electrical operation manual


 Special accessories

  • Oil cooler
  • Coolant oil
  • Gundrill
  • Guide bush
  • Rubber bush
  • Automatic Voltage stabilizer
  • Fully enclosed guard
  • Gundrill grinder
  • Safety door interlock
  • Oil mist collector
  • Filtration housing
  • Centrifuge
