Gun Drilling Machine

SL-1000

SL-1000 gun drilling machine is economical for your business. We have the most efficient motor to work the machine, and this machine is ideal for you to drill different kinds of round bar. The motor drives every workpiece counter-rotating to increase concentricity. Besides, the movable rear fixture base design is convenient during the production process since the base can help you move per length of the round bar. Please feel free to contact us for more information today.

Specification

Capacity

Number of drill spindle: 1 Quill
Range of drilling dia.: 5 ~ 25mm (option: 10~50mm)
Max. depth of drilling: 1,000mm

Speed

Drill feed range: 10 ~ 150 mm/min
Spindle speed range: 6,000 rpm

Hydraulic system

Coolant pump pressure range: 0~100 kg/cm²
Pump output range: 30~60 L/min
Coolant tank capacity: 1500 L

Working table stroke

Effective drill stroke (Z-Axis): 1,300mm

Drive motor

Spindle motor: 10hp
Z-Axis: 1hp
Chip screw: 1/8hp
Workpiece driven motor: 1/2hp
Coolant pump: 10hp
Automatic lubrication: 40w
Total machine power: 25hp

Net weight: 4,500kgs
Machine dimensions(Approx): 3,800 x 3,000 x 1,800mm

Standard accessories

Paper filter
Magnetic separator
High pressure oil pump
Tool box
Leveling screw

Special accessories

Oil cooler
Coolant oil
Gun drill
Guide bush
Gun drill grinder
Whip guard insert
