Enlarged shaft and shaft key design, which increases the working pressure and lowers noise during operation.
Gears are made of special steel that precisely machined so that the gear contact surface possesses high-precision surface roughness, which meets the requirements of high-pressure products.
Compact size and space saving, suitable for instruments and miniature precision machinery.
Aluminum alloy, gravity casting housing high strength and high density, to ensure the body shape and pump stability.
The bushing in the gear pump has the characteristics of high load and low coefficient of friction, which reduces shaft wear and increases product life.
| EGB | 16.5 | R |
| External Gear Pump | Delivery At No Load (C.C./Rev) | Direction Of Rotation |
| (View Form Shaft End) | ||
| B type Low noise External Gear Pump | 6.2 | R: Clockwise |
| 8.4 | ||
| 11 | ||
| 14.3 | ||
| 16.5 | ||
| 19.5 |
View our website to search model code, technical data, performance curve and measurement
