01
Material Thickness: with a wide range from 0.2 to 6.0mm.
Applicable Materials: Thin stainless steel, copper, iron, aluminum, and other steel materials.
Equipped with Yaskawa servo motor, enhancing feeding accuracy.
High Wear Resistance: The surface of the feeding rollers undergoes special treatment (HRC60°±2°)
Feeding Precision: Achieve accuracy of +/- 0.1mm with pneumatic release system.
02
Sectional Feeding Function: Feature 3 different feeding lengths, each capable of handling 999 feeding cycles.
User-Friendly Control Panel: Easy and quick operation through a simplified control panel.
Feeding length: Within the range of 0.001 to 9999mm.
Pneumatic Release System: Utilizing pneumatic pressure for quick and precise material movement,
Produced for: Small hardware components, automotive parts, cabinets, and electrical components, among others.
| Model | KNC-100 | KNC-200 | KNC-300 | KNC-400 | KNC-500 | KNC-600 | KNC-700 | KNC-800 |
|---|---|---|---|---|---|---|---|---|
| Coil Thickness | 0.2-3.2 | 0.2-3.2 | 0.2-3.2 | 0.2-3.2 | 0.2-3.2 | 0.2-3.2 | 0.2-3.2 | 0.2-3.2 |
| Releasing system | Air Pilot Release | |||||||
| Servo Motor | AC 0.85 | AC 0.85 | AC 0.85 | AC 1.3 | AC 1.8 | AC 1.8 | AC 1.8 | AC 2.9 |
* Join member to unlock the VIP price
* The following prices are quoted in USD dollars 【transportation and installation should be quoted upon request】
* Kutron Technology reserves the right to explain price modifications and price changes.
* The actual price is based on the official order.
* In response to market price adjustments for raw materials, there will be no further notice if there are any price changes.
* The above prices are for standard machines. If there are customized requirements, we will quote separately.
