DOUBLE COLUMN HIGH-SPEED ENGRAVING AND MACHINING CENTER
Double Column High-Speed Engraving and Machining Center
HMC-430

Features:
3 axes travel: X-400 / Y-300 / Z-220
Built-in spindle—ISO 25/24000 rpm
Full splash guard
Spindle oil cooler + air conditioning for electrical cabinet
Auto lubrication system
Coolant system
X.Y Telescopic cover
Pressure-Relief Electric Lubricator(3L)
M80 controller (OP: 0i-MF, 828D)
Tools length measurement
10 Tools armless type ATC
MPG
3 colors warning light
Leveling pads & screws

Specification

* Besides HMC-430, there are various other models;
Click the pictures above or here to our official website to see more.





MODEL UNIT HMC-430
Travel X axis mm 400
Y axis  mm 300
Z axis  mm 220
Spindle nose to table surface distance mm 60-290
Table Size mm 400x350
T-Slot mm 14x100x4
Max. loading kg 250
Spindle Power kw 4.8
Speed r.p.m 24000
Torque N.m 2.6
Lubrication system type oil-Air
Rapid Feedrate (X/Y/Z) M/min 15/15/15
Cutting Feedrate (X/Y/Z) mm/min 7500
Tools type ISO-25
ATC Tools number pcs 10
Max. tool diameter mm 12
Max. tool length mm 100
Tool Magazine type Armless
X/Y/Z servo motor kw 0.85/0.85/0.85 (B)
Coolant Pump kw 1
Machine size cm 170x200x220
Machine weight (appr.) kg 2300
