Specification
| Chemical Analysis |
Advantages |
||
|---|---|---|---|
| Specification Chemistry |
BAINITE SAE J2175 |
TEMPERED MARTENSITE SAE J827 |
1. The consumption has been reduced 2. Longer life 3. Produce cost down 4. Increase the working efficiency 5. Low the ability of discharge acid in the workpiece of diecasting 6. Reduces the collection dust filter pocket the damage |
| Carbon | 0.08 to 0.15% | 0.60 to 1.20% | |
| Silicon | 0.10 to 0.25% | 0.40% min | |
| Manganese | 1.00 to 1.50% | 0.35 to 1.20% | |
| Aluminum | 0.05 to 0.15% | --- | |
| Phosphorus | 0.35% max. | 0.050% max. | |
| Sulfur | 0.35% max. | 0.050% max. | |
| Hardness | 35~50 Rc | 40~51 Rc | |
| % Rounds and Hollows | <15% non-spherical (length>2 x width and hollows) |
<15% non-spherical (length>2 x width and hollows) |
|
| Non-magnetic Material | <1% | <1% | |
| Density | >7g/cc (wet method) | >7g/cc (wet method) | |
