Fully Automatic Band Saw
FULLY AUTOMATIC BAND SAW PIVOT TYPE
S-460HB

Specification


ModelS-460HB
Capacity420 mm (16.5")
420 x 420 mm (16.5"W x 16.5"H)
Bundle CuttingWidth195 to 300 mm (8" to 12")
Height90 to 200 mm (3.5" to 8")
Blade Speed20 to 100 m/min (65 to 330 fpm) (INVERTER)
MotorBlade Drive5.5 kW (7.5HP)
Hyd. Pump1.5 kW (2HP)
Coolant Pump0.2 kW (1/4HP)
Blade Size4570 x 41 x 1.3 mm (180" x 1.6" x 0.05")
Blade TensionHydraulic
Index Length500 mm (20")
500 mm x 9 times (20" x 9)
Machine Weight2360 kg (5190 lb)
Floor Space (L x W)2590 x 2180 mm (102" x 85.8")

* All specifications, dimensions and design characteristics shown in this catalogue are subject to change without prior notice.
