Specification
| Total Distances | Drilling Ability | Fabricated threaded guiding stroke | Weight | Speed tolerance |
|---|---|---|---|---|
| 60mm | M6(S45C) | 0.25 - 1.25mm | 28kg | 1000rpm |
| Ensure Accurate | Lubricate | Fixing screw |
|---|---|---|
| Deflection Of Spindle Face 0.015mm |
Grease | 4-M8X30L |
Consumable
| Spindle Oil Seal | Spindle Bearing | Belt Bearing |
|---|---|---|
| TC-Ø22xØ32x6 TC-Ø40xØ50x8 |
6804ZZ-3 | 6804Z-2 |
