G2 110-250 Open Back Double Crank Press
G2

The single crank, double post guide, high speed, precision and automatic press and the frame structure are made of the low heat-expansion coefficient cast iron to ensure heat-resistance, shake-proof and accuracy of the stable low dead center. On the design hand, it emphasized the importance for durability and stablity, meantime, considered the different requirements of material for every frame structure under different activity, so olease be careful to choose material, in order to achieve its highest efficiency for the different characteristics of every frame structure.

more power press machines

Specification

Type

G2-110

G2-160

G2-200

G2-250



Model

S

V

H

S

V

H

S

V

H

S

V

H

Capacity(tons)

110

160

200

250



Rated Distance Point(mm)

5

3

6

3

6

3

7

3.5



Stroke(mm)

180

110

200

130

250

150

280

170



Stroke Per Minute(S.P.M)

50

35-65

50-100

45

30-55

40-85

35

25-45

35-70

30

20-35

30-60



Open Heigh(mm)

400

450

500

550



Adjustment of Slide(mm)

100

100

120

120



Bolster Area(mm)

1800x650

2000x760

2400x840

2700x900



Thickness Of Bolster Plate(mm)

130

165

150

185

170

220

170

225



Slide Plater Area(mm)

1400x500

1600x550

1850x650

2100x700



Thickness Of Slide(mm)

70

70

95

95



滑块板孔径

φ50x3xPitch320

φ50x3xPitch350

φ50x3xPitch375

φ50x3xPitch450



Main Motor(HPxP)

10x6

Vs15x4

15x6

Vs20x4

20x6

Vs25x4

25x6

Vs30x4

Slide Adjusting Motor (HPxP)

1x4

1x4

2x4

2x4



Keeop The Air Pressure(kg/cm2)

5

5

5

5



Accuracy

JIS(CNC)一级



Model

2-Pad-2-Cylinder



Capacity(tons)

3.6x2

6.3X2

10X2

14X2



Air Pressure(kg/cm2)

6.5

7.2

6.75

9



Strokess

70

70

80

100



Pad Area(2set)

350x235x2组

410x260x2组

540x350x2

640x470x2
